APN Health Has Developed A Highly Effective And Simple 3D Cardiac Mapping System
"APN Health has developed a highly effective and simple 3D cardiac mapping system that allows physicians to confidently perform interventional procedures that are critical for the treatment of heart rhythm disorders. Navik 3D uses technology that already exists in all electrophysiology labs, which makes it affordable to a greater number of hospitals and clinics around the world. Our goal is to make this important navigational tool widely available to help ensure the best outcomes for patients with cardiac arrhythmias."
APN Health, LLC is a new medical device company that has developed proprietary and patented software algorithms to create an innovative and cost-effective 3D cardiac imaging system called Navik 3D
These algorithms are capable of using real-time 2D fluoroscopic image data to locate the precise 3D x-y-z location of cardiac catheters. This information is then incorporated with other integrated algorithms and a display screen to create 3D maps that can be used for catheter mapping and ablation of cardiac arrhythmias.
APN Health's Navik 3D technology is driven by increasing global demand for heart rhythm disorder treatments in rapidly aging populations, which are expensive procedures. The current mapping systems capable of creating 3D cardiac maps can cost anywhere from $500,000 to $3 million. The disposable catheters required by these systems, which allow a cardiologist to locate and destroy the heart tissue that's causing the irregular beats, can cost more than $3,000 each.
Jasbir Sra, a cardiac electrophysiologist with Aurora Health Care in Milwaukee, Wisconsin, set out in 2010 to find a less-expensive approach, hoping to make cardiac ablation procedures more widely available, particularly in the developing world.
The Navik 3D system creates 3D maps of a heart chamber using patient monitoring and fluoroscopic imaging systems, which already exist in hospital catheter labs, at a fraction of the cost of other mapping products world.
Future product expansion for APN Health includes the planned extension of this technology for use in other procedures requiring 3D imaging.

Navik 3D
Completed Milestones and Execution Plan

2016-2017

  • FDA clearance of first
    generation device

  • Addition of advanced
    features, 3D localization
    of cryoballon and
    Quick Map

2018

  • Q1 2018

    Launched at Aurora
    St. Luke's, Milwaukee

  • Q2 2018

    Distribution partners
    chosen

  • Q4 2018

    Launched at University of Illinois at Chicago

2019

  • More advanced high density rapid mapping investigation to start in multiple centers in US and other countries
